♦  Customizable Hardware Options – Flexible hardware configurations to suit various project needs.
♦  Customizable Software Features – Modify logic, interface, and functionalities as per application requirements.
♦  Supports White Label Branding – Ideal for OEMs to promote under their own brand identity.

♦  4 Class initiating device circuit.
    > All zones accept smoke detectors and any normally open contact device.
    > Any zone can be configured as alarm (fire) or supervisory zone.
♦  2 Class Releasing Agent Circuits (RAC).
♦  2 Class Notification Appliance Circuits (NAC).
♦  Operates on 120 – 220v 60/50hz, AC mains power supply.
♦  Standby (battery) backup 24v DC power suplly with built in charger.
♦  16×2 Dot matrix LCD display.
♦  Error free fire/fault status in unambiguous colored LED indication.
♦  System on indication.
♦  Main, standby status audible and visual indication.
♦  Battery low visual warning with audible tone.
♦  3 Form – C programmable relays for fault/supervisory/fire/pre – release/released.
♦  Programmable 24v D.C. outputs.
♦  Programmable mode (Auto/Manual) selection.
♦  Programmable RACs.
♦  Zone isolation facility with loop voltage cut off.
♦  All field wiring circuits are power limited except 120/220v AC and battery.
♦  All filed wiring circuits are supervised.
♦  AC low voltage cut off.
♦  Programmable NAC’s.
♦  Programmable supervisory mode.
♦  Programmable AC loss delay.
♦  Programmable trouble reminder facility.

♦  Quiescent current: 65 ma typical.
♦  Maximum sounder current output: 1A.
♦  Sounder saturation voltage: <1V at 1A.
♦  Zone response time: <250ms.
♦  Total current output: 2A at 230 V AC.
♦  Regulation: <9%.
♦  Ripple: <200MV RMS.
♦  Battery voltage: 12V DC.
♦  Battery type: SMF rechargeable.
♦  Battery recharge voltage: 13.8V+/-0.2V DC.

♦  Storage temperature: -20c to 60c.
♦  Maximum humidity: 95% non-condensing.
♦  Environment: residental/commercial/light industrial.
